PENTAX Series V-100N

Newly enhanced Total Station equipped with high power EDM System ‘TURBO X’

• Extended measurement range: Reflectorless mode up to 1,000 m
• Improved power efficiency: Maximum 30 hours continuous distance measurement
• Quicker measuring speed: Initial measuring 0.7 sec, Continues 0.3 sec per measurement
• 1 or 2 second angle accuracy for all standard models
• IP54 dust/water resistance protects the instrument in harsh outdoor environment
• The trigger key is embedded in the instrument to avoid the impact of jitter on the measurement

SPECIFICATIONS TOTAL STATION V-100N SERIES

Model		V-101N	V-102N	V-102NL
Telescope	Magnification	30 X
	Effective Aperture	48 mm
	Field of View	1° 30’
	Minimum Focus	1.7 m
Distance Measurement	Laser Class of Laser Pointer	Prism mode Class 1, Reflectorless mode: Class 3R
	Measurement Range (Good Conditions) *1
	Reflectorless  *2	1000 m	1000 m	600 m
	1P	3500 m
	Measurement Accuracy
	Reflectorless  ~ 200m	±(3+2ppm×D) mm
	Reflectorless 200m ~	±(5+3ppm×D) mm
	Prism /Reflector Sheet	±(2+2ppm×D) mm
	Minimum Count	Normal Meas. : 1 mm or 0.1 mm / Fast Meas. : 10 mm
	Initial Meas.         Reflectorless	Approx. 0.3 sec.
	Prism/Refl. Sheet	Approx. 0.8 sec.
	Continuous Meas.  Reflectorless	0.7 sec.
	Prism/Refl. Sheet	Approx. 0.3 sec.
	Environmental Correction	Yes
	Laser Pointer	Yes
Angle Measurement	Measuring Method	Absolute Rotary Encoder
	Detection Method	Code image Detection
	Minimum Count	1”
	Accuracy (ISO 17123-3)	1”	2”	3”
Display Type		Back light 2 Sides 320×240 color pixels
Compensator	Compensator Type	Liquid-electric
	Compensator Axis	2 Axis
	Compensator Range	±4’
Onboard Software	Functions	File Management, coordinate measurement, stakeout, resection,      reference line measurement, offset measurement,      missing line measurement, remote height measurement,      area calculation, etc.
Data Process	Data Recording Method	Internal Memory
	Capacity (Coordinates/Observation Data)	Approx. 40,000 points
Interface		USB Port (Pen Drive is supported) and Bluetooth
Sensitivity of Vials	Electrical Level	0.5”
	Tubular Level	30”/2 mm
Laser Plummet		Class 2
Base		Detachable
Dust & Water Protection		IP54 (instrument only)
Operating Temperature Range		-20 °C ~ +50 °C
Dimensions		215 x 176 x 315  mm
Weight (incl. Battery)		5.93 kg
Battery Pack (BP07)	Power Source	Li-ion 7.4V 3350mAh, equipped with 2 batteries as standard, Hot-Swappable
Operation Time	Continous Meas.	Maximum 30 hours with 2 batteries
	Angle Meas.	Maximum 50 hours with 2 batteries
Battery Charging Time		1 battery: approx. 2 hrs. / When charging 2 batteries at the same time: approx. 4 hrs.

*1 Normal or good weather conditions are based on the following conditions:
20km visibility with slight shimmer, weak sunlight and moderate wind.
*2 The measurement range and accuracy of reflectorless, and time required to measure may vary by the shape,size of surface area and reflection rate of the target and its environment.
The measurement range of reflectorless is determined by the white side of the KODAK Gray Card
(KODAK is a registered trademark of Eastman Kodak Company).
